Kyocera ecosys M2640idw User Manual

3-19
Preparation before Use > Registering Destinations in the Address Book
The Folder (SMB) Address
[SMB] > [Host Name], [Path], [Port], [Login User Name] and [Login Password] > [OK]
The table below explains the items to be entered.
To search for a folder on a PC on the network, select in the following order.
[Menu] > [Search Folder from Network] or [Search Folder by Host Name]
If you selected [Search Folder from Network], you can search all PCs on the network for a
destination.
If you selected [Search Folder by Host Name], you can enter the "Domain/Workgroup
Name", and "Host Name" to search PCs on the network for the destination.
Up to 500 addresses can be displayed. The login user name and login password entry screen
appears.
Select the host name (PC name) that you want to specify in the screen that appears > [Next].
NOTE
For the computer name, share name, domain name, and user name, enter the information
that you noted when you created the shared folder. For details on creating shared folders,
refer to the following:
Preparation for Sending a Document to a Shared Folder in a PC (page 3-8)
Item Description
Max. No. of
Characters
Host Name Computer name Up to
64 characters
Path Share name
For example: scannerdata
If saving in a folder in the shared folder:
share name\folder name in shared folder
Up to
128 characters
Port Port number
(Normally 445.)
1 - 65535
Login User Name If the computer name and domain name are the same:
User Name
For example: james.smith
If the computer name and domain name are different:
Domain name\User name
For example: abcdnet\james.smith
Up to
64 characters
Login Password Windows logon password
(Case sensitive.)
Up to
64 characters
NOTE
• Refer to the following for details on entering characters.
Character Entry Method (page 11-8)
•Select [Menu] > [Connection Test] to check the connection to the server you chose. If the
connection fails, check the entries you made.

Kyocera ecosys M2640idw Specifications

General

Paper input type	Cassette, Paper tray
Multi-Purpose tray	Yes
Total input capacity	250 sheets
Maximum input capacity	850 sheets
Total number of input trays	1
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Auto document feeder (ADF) input capacity	50 sheets
N-up printing	2, 4
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Borderless printing	No
Duplex printing mode	Auto
Time to first page (black, normal)	6.4 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	40 cpm
Scan to	E-mail, FTP, SMB, TWAIN, USB, WIA
Scan drivers	TWAIN, WIA
Scan speed (color)	23 ppm
Image formats supported	JPG, TIF
Duplex scan speed (black)	32 ppm
Duplex scan speed (color)	16 ppm
Document formats supported	PDF, XPS
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	400 x 400 DPI
Fax transmission speed	3 sec/page
Printing colors	Black
Duplex functions	Copy, Fax, Print, Scan
Maximum duty cycle	50000 pages per month
Recommended duty cycle	1000 - 2500 pages per month
Replacement cartridges	TK-1170 (7.200 pagina's)
Page description languages	Microsoft XPS, PCL 5e, PCL 6, PostScript 3
Scan media weight	50 - 160 g/m²
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 163 g/m²
Paper tray media types	Plain paper
Non-ISO print media sizes	Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Processor family	ARM Cortex-A9
Compatible memory cards	SD, SDHC
Maximum internal memory	1536 MB
Sound power level (standby)	29 dB
Sound pressure level (copying)	52 dB
Sound pressure level (quiet mode)	48 dB
Display	TFT
Control type	Touch
Product color	Black, White
Display diagonal	4.3 \
Market positioning	Business
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	2
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (ready)	21 W
Power consumption (sleep)	1 W
Power consumption (printing)	661 W
Energy Star Typical Electricity Consumption (TEC)	1.74 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Certification	TUV / GS, CE, ISO 9001, ISO 14001
Cartridge type	TK-1170
Operating altitude	0 - 3500 m
Non-operating altitude	0.6 - 15000 m
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	Blue Angel, REACH, RoHS, EPEAT Silver, ENERGY STAR
Package depth	555 mm
Package width	541 mm
Package height	572 mm
Package weight	25000 g
Cables included	AC
Included cartridge capacity (black)	3600 pages
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	412 mm
Width	417 mm
Height	437 mm
