Kyocera ECOSYS M3145dn User Manual

3-19
Preparation before Use > Preparation for Sending a Document to a Shared Folder in a PC
5 Set the access permission for the user selected.
6 Click the [OK] button in the "Advanced Sharing" screen to close the screen.
7 Check the details set in the [Security] tab.
1 If the computer name that you made a note of on page 3-15
is the same as the domain
name:
If the computer name is not shown in "From this location", click the [Locations] button,
select the computer name, and click the [OK] button.
Example: PC001
If the computer name that you made a note of on page 3-15 is not the same as the
domain name:
If the text after the first dot (.) in the full computer name that you made a note of does
not appear in "From this location", click the [Locations] button, select the text after the
dot (.), and click the [OK] button.
Example: abcdnet.com
Making a note of the user name and domain name
(page 3-16)
2 Enter the user name that you made a note of on page in the text box, and click the [OK]
button.
Also the user name can be made by clicking the [Advanced] button and selecting a
user.
NOTE
"Everyone" gives sharing permission to everyone on the network. To strengthen
security, it is recommended that you select "Everyone" and remove the "Read" [Allow]
checkmark.
1
2
3
1 Select the user you entered.
2 Select the [Allow] checkbox of the
"Change" and "Read" permissions
3 Press [OK].

Kyocera ECOSYS M3145dn Specifications

General

AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (ready)	50 W
Power consumption (sleep)	0.5 W
Power consumption (copying)	652 W
Power consumption (PowerSave)	29 W
Power consumption (average operating)	630 W
Energy Star Typical Electricity Consumption (TEC)	2.25 kWh/week
Processor cores	2
Processor family	ARM Cortex-A9
Coprocessor frequency	1.2 GHz
Card reader integrated	Yes
Compatible memory cards	SD, SDHC
Maximum internal memory	3000 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	54 dB
Paper input type	Cassette, Paper tray
Total input capacity	500 sheets
Total output capacity	250 sheets
Maximum input capacity	2600 sheets
Total number of input trays	1
Maximum number of input trays	5
Multi-Purpose tray input capacity	100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Display	LCD
Control type	Buttons
Color display	No
Product color	Black, White
Market positioning	Business
Printer fonts	Barcode, Bitmap, PCL, Windows
Printing colors	Black
Duplex functions	Copy, Print, Scan
Maximum duty cycle	150000 pages per month
Recommended duty cycle	3000 - 10000 pages per month
Replacement cartridges	TK-3160 (12.500 pagina's)
Page description languages	OpenXPS, PCL 6, TIFF, XPS
N-up printing	2, 4
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.9 s
Print speed (black, normal quality, A4/US Letter)	45 ppm
Duplex print speed (black, normal quality, A4/US Letter)	22.5 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	7 s
Copy speed (black, normal quality, A4)	45 cpm
Scan to	E-mail, FTP, SMB, TWAIN, WIA
Scan drivers	TWAIN, WIA
Grayscale levels	256
Scan speed (black)	60 ppm
Scan speed (color)	40 ppm
Image formats supported	JPEG, TIFF
Duplex scan speed (black)	26 ppm
Duplex scan speed (color)	17 ppm
Document formats supported	PDF, XPS
Custom media width	140 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 120 g/m²
Paper tray media types	Plain paper
Non-ISO print media sizes	Folio (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Envelopes, Labels, Legal, Letter, Plain paper, Recycled paper, Thick paper, Thin paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Auto Document Feeder (ADF) media weight	50 - 120 g/m²
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet, Wireless LAN
USB 2.0 ports quantity	3
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Certification	TÜV/GS, CE, ISO 9001, ISO 14001.
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Operating altitude	0 - 3500 m
Non-operating altitude	0.6 - 15000 m
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	15 - 80 %
Sustainability certificates	Blue Angel, REACH, RoHS, EPEAT Silver, ENERGY STAR
Package depth	572 mm
Package width	589 mm
Package height	695 mm
Package weight	29300 g
Cables included	AC
Included cartridge capacity (black)	6000 pages
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	476 mm
Width	475 mm
Height	575 mm
