Kyocera ECOSYS M6535cidn User Manual

3-17
Preparation before Use > Preparation for Sending a Document to a Shared Folder in a PC
3 Specify the location.
4 Set the access permission for the user selected.
Select the [Allow] checkbox of the "Change" and "Read" permissions and press [OK].
In Windows XP, go to step 6.
5 Click the [ OK ] button in the " Advanced Sharing " screen to close the screen.
NOTE
" Everyone " gives sharing permission to everyone on the network. To strengthen
security, it is recommended that you select "
Everyone " and remove the " Read " [ Allow ]
checkmark.
2
3
1
1 If the computer name that you made a note
of on page Making a note of the computer
name and full computer name on page 3-13
is the same as the domain name:
If the computer name is not shown in "From
this location", click the [
Locations ] button,
select the computer name, and click the [
OK ]
button.
Example: PC001
If the computer name that you made a note of
on page Making a note of the computer name
and full computer name on page 3-13 is not
the same as the domain name:
If the text after the first dot (.) in the full
computer name that you made a note of
does not appear in "From this location", click
the [
Locations ] button, select the text after
the dot (.), and click the [
OK ] button.
Example: abcdnet.com
2 Enter the user name that you made a note of
on page Making a note of the user name and
domain name on page 3-14 in the text box,
and click the [
OK ] button.
Also the user name can be made by clicking
the [
Advanced ] button and selecting a user.
1
1
2
3
1 Select the user you entered.

Kyocera ECOSYS M6535cidn Specifications

General

Secure printing	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Print resolution black	600 x 600 DPI
Time to first page (black, normal)	7 s
Time to first page (color, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Copier resize	25 - 400 %
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	9 s
Time to first copy (color, normal)	11 s
Scan to	E-mail, FTP, SMB, TWAIN, USB, WIA
Scan drivers	TWAIN, WIA
Scanner type	ADF scanner
Grayscale levels	256
Maximum scan area	Legal (216 x 356) mm
Scan speed (black)	60 ppm
Scan speed (color)	40 ppm
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Color faxing
Fax memory	256 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax transmission speed	3 sec/page
Digital sender	-
Maximum duty cycle	100000 pages per month
Page description languages	Epson LQ, IBM ProPrinter XL24E, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Internal memory	1024 MB
Processor model	465S
Processor family	PowerPC
Compatible memory cards	SD, SDHC
Maximum internal memory	2048 MB
Sound power level (standby)	37.6 dB
Sound pressure level (copying)	49.7 dB
Sound pressure level (quiet mode)	46.5 dB
Paper input type	Cassette, Paper tray
Total input capacity	350 sheets
Total output capacity	250 sheets
Maximum input capacity	1850 sheets
Total number of input trays	2
Maximum number of input trays	4
Multi-Purpose tray input capacity	75 sheets
Auto document feeder (ADF) input capacity	100 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Auto Document Feeder (ADF) media weight	60 - 120 g/m²
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	3
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (standby)	73 W
Power consumption (PowerSave)	2.1 W
Power consumption (average operating)	537 W
Mac operating systems supported	Mac OS X 10.5 Leopard
Other operating systems supported	Android, iOS
Sustainability certificates	ENERGY STAR
Certification	TUV/GS, CE

Weight and Dimensions

Depth	558 mm
Width	475 mm
Height	616 mm
