Kyocera ECOSYS M8124cidn User Manual

6-9
Sending Faxes from PC > Network FAX Setup
2
Configure the settings.
(1) Sending Options Tab
(2) Cover Page Tab
Item Description
Delayed transmission Check the checkbox in order to activate the time fields to the right of the checkbox
whenever you want to set the time that your documents will be transmitted. The desired
time setting can be entered directly with the keyboard or by clicking on the and
arrows.
IMPORTANT
If the time that is shown in the message display of this fax machine does not match the
current time, communications that use the timer may not be accomplished as expected. If
the displayed time is not current, be sure to adjust it to match the correct time.
NOTE
If you designate a time that is earlier in the day than the time that is actually displayed in
the fax machine itself, the transmission operation will be carried out the following day at
that time. Be sure to confirm the time setting in the fax machine itself before making this
setting.
Value: 00:00 - 23:59
Transmit and Print Check the checkbox when you want to print out the documents at the fax machine same
time as you send them by fax.
Display confirm dialog You can check the checkbox to display the destination confirmation screen and check the
destinations before transmission.

Kyocera ECOSYS M8124cidn Specifications

General

N-up printing	2, 4
Secure printing	Yes
Print technology	Laser
Resolution color	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	7.5 s
Time to first page (color, normal)	10.2 s
Print speed (black, normal quality, A3)	12 ppm
Print speed (black, normal quality, A4/US Letter)	24 ppm
Duplex print speed (black, normal quality, A4/US Letter)	22 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	7.6 s
Time to first copy (color, normal)	9.8 s
Copy speed (black, normal quality, A3)	12 cpm
Copy speed (black, normal quality, A4)	24 cpm
Scan to	E-mail, FTP, SMB, TWAIN, USB, WIA
Scan drivers	TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Maximum scan area	297 x 420 mm
Scan speed (color)	50 ppm
Image formats supported	JPEG, MMR, TIFF
Duplex scan speed (color)	16 ppm
Document formats supported	PDF, XPS
Faxing	No
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	400 x 400 DPI
Fax transmission speed	3 sec/page
Printer fonts	Barcode, Bitmap, PCL, Windows
Digital sender	-
Printing colors	Black, Cyan, Magenta, Yellow
Duplex functions	Copy, Print, Scan
Maximum duty cycle	100000 pages per month
Recommended duty cycle	2000 - 5000 pages per month
Replacement cartridges	TK-8115K, TK-8115C, TK-8115M, TK-8115Y
Number of print cartridges	4
Page description languages	Microsoft XPS, OpenXPS, PCL 5e, PCL 6, PCL XL, PostScript 3
Processor cores	2
Processor family	ARM Cortex-A9
Compatible memory cards	SD
Maximum internal memory	3000 MB
Sound pressure level (copying)	53 dB
Sound pressure level (standby)	34 dB
Paper input type	Cassette, Paper tray
Total input capacity	500 sheets
Total output capacity	280 sheets
Maximum input capacity	1600 sheets
Total number of input trays	1
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Auto document feeder (ADF) input capacity	50 sheets
Custom media width	98 - 297 mm
Maximum print size	297 x 432 mm
Custom media length	148 - 432 mm
Duplex media weight	60 - 220 g/m²
Media thickness (min)	0.11 mm
Paper tray media types	Plain paper
Non-ISO print media sizes	Folio (media size), Ledger (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Multi-purpose tray media types	Legal, Letter
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 256 g/m²
Display	TFT
Control type	Touch
Product color	Black, White
Display diagonal	4.3 \
Market positioning	Business
Email protocols	POP3, SMTP
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1575 W
Power consumption (off)	0.1 W
Power consumption (ready)	80 W
Power consumption (sleep)	0.5 W
Power consumption (PowerSave)	40 W
Power consumption (average operating)	510 W
Energy Star Typical Electricity Consumption (TEC)	1.02 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Certification	TÜV/GS, CE
Cables included	AC
Included cartridge capacity (CMY)	1500 pages
Included cartridge capacity (black)	3000 pages
Operating altitude	0 - 3500 m
Non-operating altitude	0.6 - 15000 m
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	Blue Angel, REACH, RoHS, EPEAT Silver, ENERGY STAR
Package width	760 mm
Package height	995 mm
Package weight	104000 g
Harmonized System (HS) code	84433100

Weight and Dimensions

Width	590 mm
Height	753 mm
