Kyocera ECOSYS P2040dw Service Manual

2RV/2RW/2RX/2RY/3RA-3
7-38
J0501/J0502/J0503: Cassette no feed
Condition: Mark of paper feed slippage at the paper leading edge (the pickup roller
cannot convey paper.)
When feeding from cassette 1-3, paper stops at the pickup roller and the next sensor does not turn on after
the feed clutch or PF feed clutch turns on.
J0501/J0502/J0503: Cassette no feed
Condition: A part other than the center part of the leading edge of the paper is
broken. (Paper jam occurs as paper is caught up before entering the retard roller)
When feeding from cassette 1-3, paper stops at the feed roller and the next sensor does not turn on after the
feed clutch or PF feed clutch turns on.
J0501/J0502/J0503: Cassette no feed
Condition: The center part of the paper leading edge is folded or torn (It does not
reach to the retard roller or retard roller does not rotate).
When feeding from cassette 1-3, paper stops at the retard roller and the next sensor does not turn on after the
feed clutch or PF feed clutch turns on.
Step Check description Assumed cause Measures Reference
1 Relocating the paper width
guides
The locations of the paper
width guides do not fit with
the paper size.
Relocate the paper width
guides to fit them with the
paper size.
2 Checking the pickup roller The conveying function of
the pickup roller is not
enough.
Clean the pickup roller sur-
face. If worn down, replace it.
3 Checking the paper feed
roller
The conveying function of
the paper feed roller is not
enough.
Clean the feed roller surface.
If worn down, replace it.
Step Check description Assumed cause Measures Reference
1 Checking the paper Paper curls downward. Correct or replace paper. If
difficult to replace, re-load
paper by switching top and
bottom ends or turning it over.
2 (In case paper is bent or
conveyed in skew) Check-
ing the conveying path
Paper is caught up by the
conveying guide or paper
piece.
If there is a paper piece or
foreign object on the convey-
ing side or a burr on the con-
veying side of the conveying
guide or on the parts such as
actuator, remove it or replace
it. If there is a scratch, defor-
mation or floating on the
sheet or film, correct or
replace it.
Step Check description Assumed cause Measures Reference
1 Checking the retard roller The retard roller convey-
ing force is not enough.
Clean the retard roller sur-
face. If worn down, replace it.

Kyocera ECOSYS P2040dw Specifications

General

Processor family	ARM Cortex
Built-in processor	Yes
Compatible memory cards	SD, SDHC
Sound pressure level (printing)	48.8 dB
Sound pressure level (quiet mode)	45.5 dB
Color	No
Print technology	Laser
Duplex printing mode	Auto
Time to first page (black, normal)	6.4 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Printing colors	Black
Maximum duty cycle	50000 pages per month
Recommended duty cycle	2000 - 3000 pages per month
Replacement cartridges	TK-1160 (7.200 pagina's)
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter, PCL 5e, PCL 6, PCL XL, PDF 1.7, PostScript 3, XPS
Display	LCD
Certification	TÜV-GS, CE
Product color	Black, White
Market positioning	Home & office
Display number of lines	2 lines
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (ready)	8 W
Power consumption (printing)	620 W
Power consumption (PowerSave)	0.8 W
Energy Star Typical Electricity Consumption (TEC)	1.6 kWh/week
Total input capacity	250 sheets
Maximum input capacity	850 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	802.1x RADIUS, HTTPS, IPPS, IPSEC, SNMP
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Sustainability certificates	Blue Angel, ENERGY STAR
Package depth	516 mm
Package width	500 mm
Package height	400 mm
Package weight	18000 g
Cables included	AC
Included cartridge capacity (black)	3600 pages
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	272 mm
