Kyocera ECOSYS P2040dw Service Manual

2RV/2RW/2RX/2RY/3RA-3
7-103
(15)Print out is not available from the network factor (3)
The access point (router or hub) in the network does not operate properly.
(16)Print out is not available from the network factor (4)
The router is faulty or the router setting is not proper.
2 Restarting up The main unit or the PC
does not properly start up.
Restart the main unit and
then restart the PC.
3 Replacing the Ethernet
cable
The Ethernet cable is
faulty.
Replace the Ethernet cable.
4 Changing the connection Another network is faulty. Directly connect the main unit
to the PC with the cross
cable, and then check if the
same data can be printed out.
Step Check description Assumed cause Measures Reference
1 Restarting up The router or the hub does
not properly activate.
Check if the link lamp of the
router or hub (concentrator)
turns on and restart it.
2 Reconnecting the Ether-
net cable
The Ethernet cable is not
connected properly.
If the link lamp turns off, dis-
connect and reconnect the
Ethernet cable to the router
and check if it turns on.
3 Replacing the Ethernet
cable
The Ethernet cable is
faulty.
Replace the Ethernet cable.
4 Restarting up The router, hub, PC or the
main unit do not start up
properly.
If the link lamp turns on but
network connection is
unavailable, restart the router
or hub (concentrator), and
restart the PC and main unit.
Step Check description Assumed cause Measures Reference
1 Correcting the IP address The IP address is not prop-
erly set.
Check if the main unit IP
address displayed on the sta-
tus page and system menu
matches the one at the [Port]
tab of [Printer Properties] of
the PC. If not, correct the IP
address at the PC.
2 Correcting the printer host
name
The printer host name is
not properly set.
In case of the server environ-
ment, check the printer host-
name. Next, check the
hostname at the [Port] tab of
[Printer Properties]. If differ-
ent, correct the PC side.
Step Check description Assumed cause Measures Reference

Kyocera ECOSYS P2040dw Specifications

General

Processor family	ARM Cortex
Built-in processor	Yes
Compatible memory cards	SD, SDHC
Sound pressure level (printing)	48.8 dB
Sound pressure level (quiet mode)	45.5 dB
Color	No
Print technology	Laser
Duplex printing mode	Auto
Time to first page (black, normal)	6.4 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Printing colors	Black
Maximum duty cycle	50000 pages per month
Recommended duty cycle	2000 - 3000 pages per month
Replacement cartridges	TK-1160 (7.200 pagina's)
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter, PCL 5e, PCL 6, PCL XL, PDF 1.7, PostScript 3, XPS
Display	LCD
Certification	TÜV-GS, CE
Product color	Black, White
Market positioning	Home & office
Display number of lines	2 lines
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (ready)	8 W
Power consumption (printing)	620 W
Power consumption (PowerSave)	0.8 W
Energy Star Typical Electricity Consumption (TEC)	1.6 kWh/week
Total input capacity	250 sheets
Maximum input capacity	850 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	802.1x RADIUS, HTTPS, IPPS, IPSEC, SNMP
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Sustainability certificates	Blue Angel, ENERGY STAR
Package depth	516 mm
Package width	500 mm
Package height	400 mm
Package weight	18000 g
Cables included	AC
Included cartridge capacity (black)	3600 pages
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	272 mm
