Kyocera ECOSYS P2040dw Service Manual

2RV/2RW/2RX/2RY/3RA-3
7-99
(4) Garbled characters
The printer driver was not properly installed.
(5) Data is output in monochrome
Photos printed from a PC are monochrome instead of color. (Print from Windows Photo Viewer)
2 (LCD model) Changing the
setting
[Auto Cassette] is set to
[On].
To prevent paper feed in case
no paper is available in the
cassette selected, change
[Auto Cassette Switching] to
[Off].
3 Changing the settings [Media type] at the PC side
is different from the one at
the main unit.
Check the media type setting
of the main unit cassette and
MP tray. Next, change [Media
Type] at the PC side in
[Printer Properties] > [Prefer-
ences] to match the main unit
setting.
4 Changing the settings [Media type] setting of the
main unit cassette and MP
tray is same.
Set the different media types
for the cassette and the MP
tray at the main unit.
Step Check description Assumed cause Measures Reference
1 Resetting the main power There is a communication
error.
Check if there is no job in pro-
cess in the PC and main unit.
Next, turn the main unit
power off and disconnect the
power cord. After 5s, recon-
nect the power cord and turn
the power on.
2 Checking the font list Font for special data is not
resident.
After confirming Excel or
Word output is normal, output
Font List to check fonts for
special data are resident.
3 Selecting the bitmap font The bitmap font (default
setting) is unselected.
Select the bitmap font
(default setting) and print the
data.
4 Reinstalling the printer
driver
The printer driver is faulty. Uninstall and reinstall the
printer driver.
Step Check description Assumed cause Measures Reference
1 Checking the settings The [Color Mode] setting in
the [Imaging] tab in the
print settings at the PC is
incorrect.
Check the color mode in the
[Imaging tab] in the print set-
tings at the PC and change to
"Full color" if the color mode
was set to "Black".
Step Check description Assumed cause Measures Reference

Kyocera ECOSYS P2040dw Specifications

General

Processor family	ARM Cortex
Built-in processor	Yes
Compatible memory cards	SD, SDHC
Sound pressure level (printing)	48.8 dB
Sound pressure level (quiet mode)	45.5 dB
Color	No
Print technology	Laser
Duplex printing mode	Auto
Time to first page (black, normal)	6.4 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Printing colors	Black
Maximum duty cycle	50000 pages per month
Recommended duty cycle	2000 - 3000 pages per month
Replacement cartridges	TK-1160 (7.200 pagina's)
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter, PCL 5e, PCL 6, PCL XL, PDF 1.7, PostScript 3, XPS
Display	LCD
Certification	TÜV-GS, CE
Product color	Black, White
Market positioning	Home & office
Display number of lines	2 lines
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (ready)	8 W
Power consumption (printing)	620 W
Power consumption (PowerSave)	0.8 W
Energy Star Typical Electricity Consumption (TEC)	1.6 kWh/week
Total input capacity	250 sheets
Maximum input capacity	850 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	802.1x RADIUS, HTTPS, IPPS, IPSEC, SNMP
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Sustainability certificates	Blue Angel, ENERGY STAR
Package depth	516 mm
Package width	500 mm
Package height	400 mm
Package weight	18000 g
Cables included	AC
Included cartridge capacity (black)	3600 pages
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	272 mm
