Kyocera ECOSYS P2040dw Service Manual

2RV/2RW/2RX/2RY/3RA-3
7-81
C4201: Laser error
Laser cannot be received for 1s after starting laser emission.
C6000: Broken fuser heater
1. During warm-up, the temperature detected by the thermopile does not reach 100°C/212°F even if the fuser
heater is turned on for 10s consecutively. 2. During warm-up, the temperature detected by the thermopile
does not reach Ready temperature even passing 30s after the temperature detected by the thermopile
reached 60°C/140°F.
Step Check description Assumed cause Measures Reference
1 Checking the connection The FFC terminal is not
properly connected or
faulty.
Reconnect the following FFC.
If the FFC terminal is peeled,
deformed or broken, replace
it.
• LSU (APC PWB) - Main/
engine PWB (YC505)
2 Checking the LSU The laser diode is faulty. Reattach the LSU while tak-
ing care of static electricity. If
not repaired, replace it.
3 Replacing the main/engine
PWB
The main/engine PWB is
faulty.
Replace the main/engine
PWB.
Step Check description Assumed cause Measures Reference
1 Removing a piece of paper A piece of paper resides in
the fuser unit and the ther-
mopile cannot detect tem-
perature properly.
Remove a piece of paper
remaining in the fuser unit.
2 Checking the connection The connector is not prop-
erly connected or the wire
is faulty.
Clean the terminal of the fol-
lowing wire connectors and
reconnect the connectors. If
there is no continuity, replace
the wire.
• Fuser unit - Main/engine
PWB (YC19)
• Low voltage PWB (YC103)
- Main/engine PWB (YC20)
3 Replacing the fuser unit The fuser heater is broken. Replace the fuser unit.
4 Replacing the low voltage
PWB.
The low voltage PWB is
faulty.
Replace the low voltage
PWB.
5 Replacing the main/engine
PWB
The main/engine PWB is
faulty.
Replace the main/engine
PWB.

Kyocera ECOSYS P2040dw Specifications

General

Processor family	ARM Cortex
Built-in processor	Yes
Compatible memory cards	SD, SDHC
Sound pressure level (printing)	48.8 dB
Sound pressure level (quiet mode)	45.5 dB
Color	No
Print technology	Laser
Duplex printing mode	Auto
Time to first page (black, normal)	6.4 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Printing colors	Black
Maximum duty cycle	50000 pages per month
Recommended duty cycle	2000 - 3000 pages per month
Replacement cartridges	TK-1160 (7.200 pagina's)
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter, PCL 5e, PCL 6, PCL XL, PDF 1.7, PostScript 3, XPS
Display	LCD
Certification	TÜV-GS, CE
Product color	Black, White
Market positioning	Home & office
Display number of lines	2 lines
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (ready)	8 W
Power consumption (printing)	620 W
Power consumption (PowerSave)	0.8 W
Energy Star Typical Electricity Consumption (TEC)	1.6 kWh/week
Total input capacity	250 sheets
Maximum input capacity	850 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	802.1x RADIUS, HTTPS, IPPS, IPSEC, SNMP
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Sustainability certificates	Blue Angel, ENERGY STAR
Package depth	516 mm
Package width	500 mm
Package height	400 mm
Package weight	18000 g
Cables included	AC
Included cartridge capacity (black)	3600 pages
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	272 mm
