Kyocera ECOSYS P2135d - Self Diagnostic Codes Indication

2PG/2PH
1-4-4
(2) Self diagnostic codes indication
Self diagnostic codes indication (Animation). See page 2-4-3.
Figure 1-4-4
0
1Code
Indicator
Code
Indicator
2345
67890F
2
6
1
1.6 s
1.6 s
0.8 s
0.8 s
0.8 s
0.8 s
0.8 s
0.8 s
Repeat
Example of self-diagnostic code: 2610
(Refer to the following code conversion table)
Code conversion table
Indicates the
occurrence of a self
diagnostics error.
Sequence of display
Lit (Green)
Lit (Amber)
Lit (Amber)
Off (Amber)
Off (Amber)
Off (Green)
Indication example
