Kyocera ECOSYS P2135d Service Manual

2PG/2PH
1-4-5
(3) Self diagnostic codes
Code Contents
Remarks
Causes Check procedures/corrective measures
0150 Control PWB EEPROM error
Detecting control PWB EEPROM
(U300) communication error.
Improper installation
control PWB EEPROM
(U300).
Check the installation of the EEPROM
(U300) and remedy if necessary (See page
1-5-19).
Defective control
PWB.
Replace the control PWB (See page 1-5-
19).
0420 Paper feeder communication error
Communication error between con-
trol PWB and optional paper feeder.
Improper installation
paper feeder.
Follow installation instruction carefully again.
Defective harness
between control PWB
(YC318) and paper
feeder interface con-
nector, or improper
connector insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective control
PWB.
Replace the control PWB (See page 1-5-
19).
Defective harness
between PF main
PWB (YC5) and paper
feeder interface con-
nector, or improper
connector insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness (Refer to the
service manual for the paper feeder).
Defective PF main-
PWB.
Replace the PF main PWB (Refer to the ser-
vice manual for the paper feeder).
2000 Main motor error
The main motor ready input is not
given for 2 s during the main motor is
ON.
Defective harness
between main motor
(CN1) and control
PWB (YC305), or
improper connector
insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective drive trans-
mission system of the
main motor.
Check if the rollers and gears rotate
smoothly. If not, grease the bushings and
gears. Check for broken gears and replace if
any.
Defective main motor. Replace the main motor (See page 1-5-29).
Defective control
PWB.
Replace the control PWB (See page 1-5-
19).

Kyocera ECOSYS P2135d Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	6 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Printing colors	Black
Maximum duty cycle	50000 pages per month
Number of print cartridges	1
Page description languages	Diablo 630, Epson LQ, IBM ProPrinter, PCL 5c, PCL 6, PCL XL, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	300 sheets
Total output capacity	- sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Maximum number of input trays	4
Multi-Purpose tray input capacity	50 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Mobile printing technologies	Not supported
Standard interfaces	USB 2.0
Optional connectivity	Wireless LAN
Processor family	PowerPC
Maximum internal memory	544 MB
Sound power level (standby)	30.4 dB
Sound pressure level (printing)	53.3 dB
Sound pressure level (quiet mode)	50 dB
Display	LED
Certification	TÜV/GS, CE
Product color	Black, White
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	7.1 W
Power consumption (printing)	535 W
Power consumption (PowerSave)	2.6 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	250 mm
