Kyocera ECOSYS P3055dn Service Manual

2T6/2T7/2T8/2T9
2-3-11
YC20 17 GND - - Ground
Connected to
the main
PWB
18 USBH_DP3 I/O Analog
19 USBH_DN3 I/O Analog
20 GND - - Ground
21 SDIF_DAT0 I/O DC0V/3.3V
22 SDIF_DAT1 I/O DC0V/3.3V
23 SDIF_DAT2 I/O DC0V/3.3V
24 SDIF_DAT3 I/O DC0V/3.3V
25 SDIF_SDCLK I DC0V/3.3V
26 GND - - Ground
27 SH1D I DC0V/3.3V
28 GND - - Ground
29 LDOUT_1_DN I LVDS
30 LDOUT_1_DP I LVDS
31 GND - - Ground
32 GND - - Ground
33 GND - - Ground
34 GND - - Ground
35 GND - - Ground
36 GND - - Ground
37 GND - - Ground
38 GND - - Ground
39 LVU_SLEEP_
N
I DC0V/3.3V
40 POWER_SW O DC0V/3.3V
41 E2C_IRN O DC0V/3.3V
42 E2C_WKUP_
BGD_N
O DC0V/3.3V
43 ENG_HLDN I DC0V/3.3V
44 C2E_QUICK_
START
I DC0V/3.3V
45 PVSYNC O DC0V/3.3V VSYNC
46 GND - - Ground
47 P2C_WKUP_
RDY
O DC0V/3.3V
48 ENERGYSAV
ERKEY_N
O DC0V/3.3V
49 C2P_RST_N I DC0V/3.3V Panel reset signal
50 P2C_SDAT O DC0V/3.3V Panel received data sjgnal
Connector Pin Signal I/O Voltage Description

Kyocera ECOSYS P3055dn Specifications

General

Wi-Fi	-
Security algorithms	HTTPS, IPPS, IPSEC, SSL/TLS
Web-based management	Yes
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Color	No
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	6.6 s
Print speed (black, normal quality, A4/US Letter)	55 ppm
Printing colors	Black
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter XL24E, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (off)	0.9 W
Power consumption (ready)	11 W
Power consumption (printing)	675 W
Noise level (ready)	27.1 dB
Maximum internal memory	2560 MB
Sound pressure level (printing)	54.7 dB
Sound pressure level (quiet mode)	50.4 dB
Display	LED
Certification	TÜV-GS, CE
Product color	Black, White
Display number of lines	5 lines
Paper input type	Cassette, Paper tray
Total input capacity	500 sheets
Total output capacity	- sheets
Maximum input capacity	2600 sheets
Maximum number of input trays	6
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 120 g/m²
Maximum media length	915 mm
Paper tray media types	Banner, Plain paper
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	2
Other operating systems supported	Android, iOS
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	416 mm
Width	380 mm
Height	320 mm
