2T6/2T7/2T8/2T9

1-2-3

1. Remove two tapes.

2. Remove the protection sheet.

Figure 1-2-3

3. Remove four tapes.

Figure 1-2-4

Removing the tapes and pads

Protection sheet

Tape
