Kyocera ECOSYS P3055dn Service Manual

2T6/2T7/2T8/2T9
1-4-13
1830 Paper feeder 4 communica-
tion error
A communication error is
detected 10 times in succes-
sion.
Improper installa-
tion paper feeder.
Follow installation instruction carefully again.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
PF main PWB (YC3) and engine PWB
(YC22)
Defective PF main
PWB.
Replace the PF main PWB (Refer to the ser-
vice manual for the paper feeder).
1900 Paper feeder 1/BPF paper
feeder EEPROM error
When writing the data, the
write data and the read data is
not in agreement.
Defective PF main
PWB.
Replace the PF main PWB or the BPF main
PWB (Refer to the service manual for the
paper feeder).
Device damage of
EEPROM.
1910 Paper feeder 2 EEPROM
error
When writing the data, the
write data and the read data is
not in agreement.
Defective PF main
PWB.
Replace the PF main PWB (Refer to the ser-
vice manual for the paper feeder).
Device damage of
EEPROM.
1920 Paper feeder 3 EEPROM
error
When writing the data, the
write data and the read data is
not in agreement.
Defective PF main
PWB.
Replace the PF main PWB (Refer to the ser-
vice manual for the paper feeder).
Device damage of
EEPROM.
1930 Paper feeder 4 EEPROM
error
When writing the data, the
write data and the read data is
not in agreement.
Defective PF main
PWB.
Replace the PF main PWB (Refer to the ser-
vice manual for the paper feeder).
Device damage of
EEPROM.
2000 Main motor drive error
The main motor is not stabi-
lized within 2 s after driving
starts.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Main motor and engine PWB (YC4)
Defective drive
transmission sys-
tem of the main
motor.
Check if the rollers and gears rotate
smoothly. If not, grease the bushes and
gears. Check for broken gears and replace if
any.
Defective main
motor.
Replace the main motor.
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-22).
Code Contents Causes
Check procedures/
corrective measures

Kyocera ECOSYS P3055dn Specifications

General

Wi-Fi	-
Security algorithms	HTTPS, IPPS, IPSEC, SSL/TLS
Web-based management	Yes
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Color	No
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	6.6 s
Print speed (black, normal quality, A4/US Letter)	55 ppm
Printing colors	Black
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter XL24E, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (off)	0.9 W
Power consumption (ready)	11 W
Power consumption (printing)	675 W
Noise level (ready)	27.1 dB
Maximum internal memory	2560 MB
Sound pressure level (printing)	54.7 dB
Sound pressure level (quiet mode)	50.4 dB
Display	LED
Certification	TÜV-GS, CE
Product color	Black, White
Display number of lines	5 lines
Paper input type	Cassette, Paper tray
Total input capacity	500 sheets
Total output capacity	- sheets
Maximum input capacity	2600 sheets
Maximum number of input trays	6
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 120 g/m²
Maximum media length	915 mm
Paper tray media types	Banner, Plain paper
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	2
Other operating systems supported	Android, iOS
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	416 mm
Width	380 mm
Height	320 mm
