Kyocera ECOSYS P3055dn Service Manual

2T6/2T7/2T8/2T9-1
1-4-15
2330 Fuser pressure release
motor error
(Over-current)
The over-current detection
signal of the motor is detected
continuously twenty times.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Fuser pressure release motor and relay-L
PWB(YC11)
Relay-L PWB(YC3) and engine PWB(YC2)
Defective drive
transmission sys-
tem of the fuser
pressure release
motor.
Check if the gears rotate smoothly. If not,
grease the bushes and gears. Check for
broken gears and replace if any.
Defective fuser
pressure release
motor.
Replace the fuser pressure release motor.
Defective PWB. Replace the relay-L PWB or engine PWB.
(See Page 1-5-24,1-5-22)
2340 Fuser pressure release
motor error
(Timeout)
The position detection sensor
is not detected continuously
for 30 s.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Fuser pressure release motor and relay-L
PWB(YC11)
Relay-L PWB(YC1) and engine PWB(YC2)
Defective drive
transmission sys-
tem of the fuser
pressure release
motor.
Check if the gears rotate smoothly. If not,
grease the bushes and gears. Check for
broken gears and replace if any.
Defective fuser
pressure release
motor.
Replace the fuser pressure release motor.
Defective PWB. Replace the relay-L PWB or engine PWB.
(See Page 1-5-24,1-5-22)
2600 PF drive motor 1 error
(paper feeder 1)
When the PF drive motor is
driven, error signal is detected
continuously for 2 s.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
PF drive motor 1 and PF main PWB (YC6)
Defective drive
transmission sys-
tem of the PF drive
motor.
Check if the rollers and gears rotate
smoothly. If not, grease the bushes and
gears. Check for broken gears and replace if
any.
Defective PF drive
motor.
Replace the PF drive motor 1.
Defective PF main
PWB.
Replace the PF main PWB (Refer to the ser-
vice manual for the paper feeder).
Code Contents Causes
Check procedures/
corrective measures

Kyocera ECOSYS P3055dn Specifications

General

Wi-Fi	-
Security algorithms	HTTPS, IPPS, IPSEC, SSL/TLS
Web-based management	Yes
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Color	No
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	6.6 s
Print speed (black, normal quality, A4/US Letter)	55 ppm
Printing colors	Black
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter XL24E, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (off)	0.9 W
Power consumption (ready)	11 W
Power consumption (printing)	675 W
Noise level (ready)	27.1 dB
Maximum internal memory	2560 MB
Sound pressure level (printing)	54.7 dB
Sound pressure level (quiet mode)	50.4 dB
Display	LED
Certification	TÜV-GS, CE
Product color	Black, White
Display number of lines	5 lines
Paper input type	Cassette, Paper tray
Total input capacity	500 sheets
Total output capacity	- sheets
Maximum input capacity	2600 sheets
Maximum number of input trays	6
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 120 g/m²
Maximum media length	915 mm
Paper tray media types	Banner, Plain paper
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	2
Other operating systems supported	Android, iOS
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	416 mm
Width	380 mm
Height	320 mm
