Kyocera ECOSYS P3145dn User Manual

10-11
Troubleshooting > Troubleshooting
Troubleshooting
Solving Malfunctions
The table below provides general guidelines for problem solving.
If a problem occurs with your machine, look into the checkpoints and perform procedures indicated on the following
pages. If the problem persists, contact your Service Representative.
Machine Operation Trouble
When the following machine operation troubles occur, implement appropriate procedures.
NOTE
When contacting us, the serial number will be necessary.
To check the serial number, refer to the following:
Checking the Equipment's Serial Number (page i)
Symptom Checkpoints Corrective Actions
Reference
Page
An application does not
start.
Is the Auto Panel Reset time short? Set the Auto Panel Reset time to 30
seconds or more.
page 8-31
The screen does not
respond when the power
switch is turned on.
Check the power cord. Connect both ends of the power cord
securely.
―
Blank sheets are ejected. ― Check that the settings of the
application software.
―
Paper often jams. Is the paper loaded correctly? Load the paper correctly. page 3-2
― Turn the orientation 180 degrees around
in which the paper is positioned.
page 3-2
Is the paper of the supported type? Is it
in good condition?
Remove the paper, turn it over, and
reload it.
page 3-4
Is the paper curled, folded or wrinkled? Replace the paper with new paper. page 3-4
Are there any loose scraps or jammed
paper in the machine?
Remove any jammed paper. page 10-24
2 or more sheets are
overlaps when ejected.
(multi feed)
― Load the paper correctly. page 3-2

Kyocera ECOSYS P3145dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.3 s
Print speed (black, normal quality, A4/US Letter)	45 ppm
Duplex print speed (black, normal quality, A4/US Letter)	22.5 ppm
Printing colors	Black
Maximum duty cycle	150000 pages per month
Recommended duty cycle	5000 - 15000 pages per month
Replacement cartridges	TK-3160 (12.500 pagina's)
Number of print cartridges	1
Page description languages	OpenXPS, PCL 5c, PCL 6, PCL XL, PDF, PostScript 3, TIFF, XPS
Paper input type	Cassette, Paper tray
Total input capacity	500 sheets
Total output capacity	250 sheets
Maximum input capacity	2600 sheets
Maximum number of input trays	5
Multi-Purpose tray input capacity	100 sheets
Custom media width	140 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	210 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Multi-purpose tray media types	Legal, Letter
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Cabling technology	10/100/1000Base-T(X)
Security algorithms	HTTPS, IPPS, IPSEC, IPSec, SNMPv3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
USB connector	USB Type-A
Standard interfaces	RJ-45, USB 2.0
Optional connectivity	Ethernet, Parallel, Wireless LAN
USB 2.0 ports quantity	2
Internal memory	512 MB
Processor model	A9
Processor family	ARM Cortex
Processor frequency	1200 MHz
Compatible memory cards	SD, SDHC
Maximum internal memory	2560 MB
Sound pressure level (printing)	53.7 dB
Sound pressure level (quiet mode)	50 dB
Display	LCD
Certification	GS, TÜV, CE
Product color	Black, White
Market positioning	Home & office
Display number of lines	5 lines
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (ready)	10 W
Power consumption (printing)	594 W
Power consumption (PowerSave)	0.5 W
Energy Star Typical Electricity Consumption (TEC)	2.06 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.9 Mavericks
Cables included	AC
Included cartridge capacity (black)	6000 pages
Sustainability certificates	Blue Angel, ENERGY STAR
Package depth	494 mm
Package width	549 mm
Package height	403 mm
Package weight	19000 g
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	416 mm
Width	390 mm
Height	308 mm
Weight	14600 g
