Kyocera ECOSYS P6235cdn User Manual

8-30
Setup and Registration (System Menu) > System Menu
Disp. Status/Log
[Menu] key > [▲] [▼] key > [Device Common] > [OK] key > [▲] [▼] key > [Disp. Status/Log] > [OK] key
USB KeyboardType
[Menu] key > [▲] [▼] key > [Device Common] > [OK] key > [▲] [▼] key > [USB KeyboardType] > [OK] key
Bluetooth Set.
[Menu] key > [▲] [▼] key > [Device Common] > [OK] key > [▲] [▼] key > [Bluetooth Set.] > [OK] key
Low Toner Alert
[Menu] key > [▲] [▼] key > [Device Common] > [OK] key > [▲] [▼] key > [Low Toner Alert] > [OK] key
FormFeed TimeOut Receiving print data from the computer, the machine may sometimes wait if there is no
information signaling that the last page does not have any more data to be printed. When the
preset timeout passes, the machine automatically prints paper. The options are between 5 and
495 seconds.
Value: 5 to 495 seconds (in 5 second increments)
Ping Timeout Set the time until timeout occurs when [Ping] is executed in "Network".
Value: 1 to 30 seconds
(in 1 second increments)
*1 Displayed only when the optional Card Authentication Kit is activated.
*2 Displayed when the optional Network Interface Kit or Wi
reless Network Interface Kit is installed.
Item Description
Disp. Status/Log Set the display method of the Status/Log.
JobsDetailStatus Value: Show All, My Jobs Only, Hide All
Jobs Log Value: Show All, My Jobs Only, Hide All
Item Description
USB KeyboardType Select the type of USB keyboard that you want to use.
Value: US, Europe US, France, Germany, UK-English
Item Description
Off/On Use Bluetooth Keyboard.
Value: Off, On
Search Device Select the keyboard to be used.
Item Description
Low Toner Alert Set the amount of remaining toner to notify the administrator when to order a toner when the
toner is running low.
Value: Off,
On
Toner Level: Set the toner level for
notification of low toner.
The setting range is 5 to 100% (in 5% increments). Displayed when
[Off/On] is set to [On].
NOTE
Selecting [Off] alerts you low toner when the amount of remaining toner becomes 5%.
Item Description

Kyocera ECOSYS P6235cdn Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Time to first page (color, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Duplex print speed (black, normal quality, A4/US Letter)	32 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Replacement cartridges	TK-5280K, TK-5280M, TK-5280Y, TK-5280C
Number of print cartridges	-
Page description languages	PCL 5c, PCL 6, PCL XL, PostScript 3, XPS
Paper input type	Cassette, Paper tray
Total input capacity	500 sheets
Total output capacity	- sheets
Maximum input capacity	2100 sheets
Total number of input trays	1
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Folio (media size), Ledger (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Legal, Letter, Plain paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Standard interfaces	RJ-45, USB 2.0
Optional connectivity	Wireless LAN
Storage media	HDD
Processor cores	2
Processor family	ARM Cortex
Maximum internal memory	3000 MB
Internal storage capacity	128 GB
Sound power level (standby)	30 dB
Sound pressure level (printing)	52 dB
Certification	TÜV/GS, CE
Product color	Black, White
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (ready)	74 W
Power consumption (standby)	0.6 W
Power consumption (printing)	523 W
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks

Weight and Dimensions

Depth	532 mm
Width	390 mm
Height	469.5 mm
