Kyocera ECOSYS P6235cdn User Manual

8-3
Setup and Registration (System Menu) > System Menu
Menu Settings
This section explains the functions that can be configured in Menu. To configure the settings, select the item in System
Menu and select the setting item. For details on each function, see the table below.
Item Description Reference Page
Report Print Configure settings for printing reports and histories. page 8-5
Job Log History page 8-6
Counter This counts the number of pages printed. page 2-36
Paper Settings Configure settings for paper. page 8-7
Print Settings Configure settings for printing. page 8-10
Network Configures network settings. page 8-12
Primary Network Specify the network to be used for the send function, the network
authentication and connecting to external address book.
page 8-12
Optional Network Configure settings for the optional Network Interface Kit or Wireless
Network Interface Kit.
page 8-22
Language Select the language displayed on the message display. page 8-25
Def. Screen(Box) Select the screen to be displayed when [Document Box] key is selected. page 8-25
Date Setting Configure settings related to the date and time. page 8-25
Buzzer Set options for buzzer sound during the machine operations. page 8-26
RAM Disk Setting A RAM disk can be created and its size can be set. page 8-26
Format SSD Format an optional SSD. page 8-26
Format SD Card Format an optional SD/SDHC memory card. page 8-27
Display Bright. Set the brightness of the message display. page 8-27
Error Handling Select whether to cancel or continue the job when error has occurred. page 8-27
ColorToner Empty Select whether printing is prohibited or the Print in Black and White
setting is used for printing once the color toner runs out.
page 8-27
Timer Setting Configure settings related to the time. page 8-28
Disp. Status/Log Set the display method of the Status/Log. page 8-30
USB KeyboardType Select the type of USB keyboard that you want to use. page 8-30
Bluetooth Set. Set the Bluetooth keyboard. page 8-30
Low Toner Alert Set the amount of remaining toner to notify the administrator when to
order a toner when the toner is running low.
page 8-30
Security The security functions can be set up to protect printer operation and the
print data.
page 8-31
I/F Block Set. This allows you to protect this machine by blocking the interface with
external devices such as USB hosts or optional interfaces.
page 8-31
Security Level The Security Level setting is primarily a menu option used by service
personnel for maintenance work. There is no need for customers to use
this menu.
—
Data Security Configure settings for data stored in the optional SSD and machine's
memory.
page 8-32

Kyocera ECOSYS P6235cdn Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Time to first page (color, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Duplex print speed (black, normal quality, A4/US Letter)	32 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Replacement cartridges	TK-5280K, TK-5280M, TK-5280Y, TK-5280C
Number of print cartridges	-
Page description languages	PCL 5c, PCL 6, PCL XL, PostScript 3, XPS
Paper input type	Cassette, Paper tray
Total input capacity	500 sheets
Total output capacity	- sheets
Maximum input capacity	2100 sheets
Total number of input trays	1
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Folio (media size), Ledger (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Legal, Letter, Plain paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Standard interfaces	RJ-45, USB 2.0
Optional connectivity	Wireless LAN
Storage media	HDD
Processor cores	2
Processor family	ARM Cortex
Maximum internal memory	3000 MB
Internal storage capacity	128 GB
Sound power level (standby)	30 dB
Sound pressure level (printing)	52 dB
Certification	TÜV/GS, CE
Product color	Black, White
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (ready)	74 W
Power consumption (standby)	0.6 W
Power consumption (printing)	523 W
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks

Weight and Dimensions

Depth	532 mm
Width	390 mm
Height	469.5 mm
