Kyocera FS-2020D Operation Guide

Using the Operation Panel 2-57
Format (Formatting hard disk)
A new hard disk must be formatted before it can be used in the printer.
Formatting allows data to be written to the hard disk.
This menu is displayed only when the optional hard disk is installed on
the printer.
1 Press Z while >Hard Disk > is displayed.
2 >>Format appears.
3 Press [OK]. A question mark (?) appears.
4 Press [OK].
Processing appears and formatting of the hard disk starts. When
the formatting is successfully completed, the display returns to
Ready.
Memory Card (Using the CF card)
The printer is equipped with a slot for a CF card (memory card). By
inserting a CF card into the printer, the following operations become
available.
• Format (Formatting CF card)
For details about the handling of the CF card, refer to CompactFlash
(CF) Card on page 3-6.
1 Press Z while Device Common > is displayed.
2 Press U or V repeatedly until >Memory Card > appears.
Note Formatting will destroy any existing data on a storage device
including a used CF card.
Formatting of the hard disk must be executed from the printer.
>>Format ?
Note The Memory Card menu options are only displayed when
a CF card is installed in the printer
.
>Memory Card >

Kyocera FS-2020D Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Memory type	DDR2
Processor model	PowerPC 440
Maximum internal memory	1152 MB
Sound power level (standby)	29 dB
Sound pressure level (printing)	52 dB
Power supply type	220/240 V, 50/60 Hz
Capacity cartridge	12000 sheets
Power consumption (active)	560 W
Recommended monthly print volume	20000 pages
Maximum duty cycle	150.000 pages per month
Number of print cartridges	1
Total input capacity	500 sheets
Total output capacity	250 sheets
Maximum input capacity	1100 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	100 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	9.2 W
Power consumption (PowerSave)	5.7 W
Energy Star Typical Electricity Consumption (TEC)	2.6 kWh/week
Display	LCD
Certification	GS, TüV, CE
Standard interfaces	Parallel, USB 2.0
Optional connectivity	Ethernet, Wireless LAN
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	382 x 394 x 285 mm
