4-4
4. Selecting the Printer Settings
● Selecting the serial interface settings
Select “Serial” and then touch the “Detail” key. The [Serial] screen
will appear.
Use the “▲” and “▼” cursor keys to select the desired item and then
touch the “Change” key. The setting screen for the selected item will
appear.
Baud rate: Sets the Baud Rate 3.
Data Bits: Sets the data bit length 4.
Stop Bits: Sets the stop bit length 5.
Parity: Sets the parity 6.
Protocol: Sets the protocol 7.
Barcode: Turns the barcode mode ON/OFF 8.
Select the desired setting for each item and then touch the “Close”
key. The display will return to the [Serial] screen.
3
● Selecting the network interface
Select “Network” and then touch the “Detail” key. The [Network]
screen will appear.
Use the “▲” and “▼” cursor keys to select the desired item and then
touch the “Change” key. The setting screen for the selected item will
appear.
Netware: Turns NetWare ON/OFF 9 and selects the
NetWare Frame type 0.
TCP/IP: Turns TCP/IP ON/OFF !, DHCP ON/OFF @
and sets the IP address #, Subnet Mask $
and the Gateway address %.
Ether talk: Selects the Ether Talk setting ^.
Option Status Page: Selects the setting for the Network Card Status
Page print out &.
1
2
1
2
To Next Page
