4-56 Using the Operation Panel
Duplex (Setting the duplex printing)
Using the duplexer, you can automatically print on both sides of the paper.
The duplexer is mounted underneath the printer.
Duplex printing is only available for those media types that can be fed
from one of the cassettes.
Duplex printing is available for the following paper(media) types:
PLAIN
PREPRINTED
BOND
RECYCLED
ROUGH
LETTERHEAD
COLOR
COATED
PREPUNCHED
HIGH QUALITY
IMPORTANT Duplex printing for coated paper (Coated) is possible if
the optional paper feeder PF-510 is installed.
Binding Modes
Binding refers to the manner in which printed pages of paper are joined
together (by gluing, stitching, etc.) in book form. The two possible types
of binding are: Bind Long Edge, in which pages are joined together along
their long edge; and Bind Short Edge, in which they are joined together
along their short edge. In selecting a binding type, you must also consider
the orientation of the printed page. You can use Bind Long Edge or Bind
Short Edge with either landscape or portrait printing.
Depending on the binding type and print orientation, the duplexer
provides four types of binding. These are: (1) portrait, Bind Long Edge,
(2) portrait, Bind Short Edge, (3) landscape, Bind Long Edge, and (4)
landscape, Bind Short Edge. The figure below shows these binding
methods.
Note Duplex printing can be also performed from the MP tray. If
the paper to be fed from the MP tray does not match the paper
size and paper type of the current paper feed source cassette, a
paper jam may occur.
To Next Page
