Enhancement device setup procedure > Optional device installation
[CONFIDENTIAL]
<F> 4000 Sheet Finisher (DF-9100) to Inverter and Decurler Unit (DE-9100)
Preparation for Inverter and Decurler Unit (DE-9100)
21
Open front right upper [A] and front left upper cover [B] of DE-9100. Put the label [C]
on exit upper inner cover as shown in picture. The label is accessory of DE-9100.
Close front right cover [A] and front left cover [B].
0
• All tapes and packing materials on the accessories parts have to be removed.
• Main power switch of main unit has to be turned off and power cable has to be unplugged before install (DF-
9100).
• Folding Unit (BF-9110) and/or punch unit (PH-7A/7C/7D) has to be installed first in case of using them.
• See 4000 Sheet Finisher (DF-9100)
for unpacking.
[B]
To Next Page
