Kyocera PH-7D - Page 198

3-120
Enhancement device setup procedure > Optional device installation
[CONFIDENTIAL]
29
Open front upper cover [A].
30
Open front lower cover [A] (Screw x1). The screw will use in step 39.
NOTE
• The front lower cover [A] is not secured with screw in case that BF-9110 has installed.
[A]
[A]
[A]
