3-123
Enhancement device setup procedure > Optional device installation
[CONFIDENTIAL]
35
Put back the wrench [A] to original position (Screw x1). Screw was removed in step
33.
36
Adjust the level.
1 Loosen 2 screws [A] on the left front and rear of DF-9100. Turning the bolt [B] with screw driver clockwise
makes the distance [F] in step 28 shorter and counterclockwise makes it longer
2 Secure 2 screws [A].
[A]
[B]
[B]
[A]
[A]
