3-126
Enhancement device setup procedure > Optional device installation
[CONFIDENTIAL]
42
Push the lock frame [A] slowly as the rear side connector of DE- 9100 gets
connection. Secure the lock frame [A] (Screw x1). Screw was removed in step 40.
43
Attach staple cartridge [A] to DF-9100 front [B]. Close the front upper cover [C].
[A]
[A]
[B]
[C]
