3-151
Enhancement device setup procedure > Optional device installation
[CONFIDENTIAL]
40
Remove the connector plate [A] from the [DF] position (Screw x1, Harness Clamp x1).
41
Switch plate [A] from the [DF] position to the [ST] position (Screw x2).
42
Attach the connector plate [A] to the [ST] position (Screw x1, Harness Clamp x2).
[A]
[DF]
[ST]
[A]
[A]
[ST]
[DF]
[A]
[DF]
[ST]
