3-198
Enhancement device setup procedure > Optional device installation
[CONFIDENTIAL]
4
Insert the projection [C] on rail front [A] to front hole [B] in DF-9100. Secure the rail
front [A] (Screw x2: M4x12).
5
Insert the projection [C] on rail rear [A] rear hole [B] in DF-9100. Secure the rail rear
[A] (Screw x2: M4x12).
[A]
[C]
[B]
[A]
[A]
[B]
[A]
[C]
