3-228
Enhancement device setup procedure > Optional device installation
[CONFIDENTIAL]
7
Put cushion [B] on to bracket [A].
8
Put two bracket [A] on the rear side of main frame (screws x2 each). Insert the pole
[B] adjusting the height of light and tighten the screws.
9
Wrap USB cable [B] twice around ferrite core [A].
[A]
[B]
[A]
[B]
[A]
[B]
