16
9. Cautions when using Test Leads
Do not connect the Precision Measurement Test Leads where electrical
potentials exceeding 33Vrms with peak value of 46V or DC70V.
Please use the Simplified Measurement Test Leads for voltage measure-
ments. The Alligator clips need to be attached and used under CAT. III/
IV test environments and the Flat Test Bars are under CAT. II test
environment.
Alligator clip
Flat Test Bar
Precision Measurement Test Leads
Simplified Measurement Test Leads
8. Notes on Housing Case & Accessories
8-1 Case Lid
Case lid can be fit under the housing case while making measurement.
8-2 How to Fit Strap Belt
The instrument is equipped with a strap belt to suspend from the neck to
allow both hands to be used freely for easy and safe operation
To Next Page
