System components
System components
Loudspeaker enclosures
Kara IIi 2-way active WST
®
enclosure: 2 × 8" LF + 3" HF diaphragm (installation version)
SB18 IIi High power compact subwoofer: 1 x 18" (installation version)
KS21i High power compact subwoofer: 1 x 21" (installation version)
KS28 Flyable subwoofer 2 x 18''
SB28 High power subwoofer: 2 x 18''
Powering and driving system
LA2Xi / LA4X / LA8 /
LA12X
Amplied controller with DSP, preset library and networking capabilities
Refer to the LA2Xi / LA4X / LA8 / LA12X owner's manual for operating instructions.
Loudspeaker cables
speaker cable 2.5mm
2
cable
Speaker cable used to connect enclosures in parallel. Adapt the cable length to the installation.
speaker cable 4 x 2.5mm
2
cable
Speaker cable used to connect 2-way active enclosures in parallel. Adapt the cable length to
the installation.
custom 4-point
speakON cable
4-point speakON cable (2.5mm
2
gauge) to bare wire cable
This cable needs to be custom made.
Information about the connection of the enclosures to the LA amplied controllers is given in
this document.
Refer to the LA2Xi / LA4X / LA8 / LA12X owner's manual for detailed instructions about the whole cabling
scheme, including modulation cables and network.
Rigging elements
M-BARi Extension bar for rigging frame (installation version)
KARAIIi-RIGBAR Rigging bar and pullback for Kara IIi and SB18 IIi
KARAIIi-BUMP Flying frame for vertical deployment of Kara IIi and SB18 IIi
CLAMP250 Clamp certied for 250 kg
KARAIIi-LINK Rigging plates for Kara IIi
KARAIIi-ENDLINK End rigging plates for Kara IIi
KARAIIi-TILT Rigging element with angles for Kara IIi above or under SB18 IIi
SB18IIi-LINK Rigging plates for SB18 IIi
SB18IIi-ENDLINK End rigging plates for SB18 IIi
KARAIIi-FIXBRACKET Fastening brackets for Kara IIi and SB18 IIi
KARAIIi-TILTBRACKET Fastening brackets with angles for Kara IIi
Transportation accessories
KARAIIi-SCREEN Acoustically transparent front screen for Kara IIi
8 Kara IIi owner's manual (EN) version 2.0
