Rigging system description
Two runners on each KS21-OUTRIG bar ensure stability. Four Ø 6.5 mm holes are available to secure the assembly to the
oor.
⌀6.5 mm hole (x4)
K2-JACK
K2-JACK is a set of two bars and four feet with screw jacks and hand wheels. K2-JACK can be tted onto KS21-
CHARIOT (p.21) to improve stability or correct oor discrepancies.
During transportation, make sure the bolts are tightened.
bolts (x4)
feet with screw jacks
locking handles
hand wheels
storage position position in use
KS21 owner's manual (EN) version 2.1 19
