Inspection and preventive maintenance
A15 Wide/Focus and A-MOUNT pole-mounted on KS21
the bottom inserts are not damaged
all screws are tightened
the angle axis is not bent
Threaded knobs (p.41)
make sure that either the locking
cotter pin or the knob is present
Make sure the pole is compatible
with the KS21 pole socket. Refer to
KS21 (p.12) for more information.
Pole-mount socket (p.40) Runners and corner stops (p.38)
32 KS21 owner's manual (EN) version 2.1
