Table 12: Recommended power amplification and MLS switch settings for MTD115b high section
MTD115b HI SECTION AMPLIFIER OUTPUT POWER
REC'D POWER (MLS SETTING)
LOAD REC'D LA15a LA 17a LA 24a LA 48a
(ohms) POWER
2 2400 do not use 1200 1700
2400
(0 dB) (0 dB)
(-2 dB)
2.7 1760 do not use 1080
1635 1665
(0 dB)
(0 dB) (-4 dB)
4 1200 600
840 1300 1000
(0 dB)
(0 dB)(-2 dB)(-4 dB)
8 600 370
430 700 520
(0 dB)
(0 dB)(-2 dB)(-4 dB)
MLS switch settings for powering the MTD115b in active mode are summarized in Table 13.
Table 13: Recommended MLS switch settings for powering MTD115b (active mode)
MTD115b (ACTIVE) MLS SETTING
LA15a LA17a LA24a LA48a
MTD115b LO SECTION 0 dB 0 dB -2 dB -4 dB
MTD115b HI SECTION 0 dB 0 dB -2 dB -4 dB
