52
Read all instructions before installing or using this appliance.
Installation Instructions
Save these instructions for future reference.
Schematic diagram of the Range
Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause
improper and dangerous operation. Verify proper operation after servicing.
Code Description
ROE Convection hand oven element
CFM Convection Oven fan motor
CVL Convection Oven light bulb
CLS Convection Oven light switch
RSB Convection oven switch block
OTL Convection oven thermostat
OTR Convection oven thermostat
FMC Cooling fan motor
ISG Ignition spark module
IGS Ignition switches
LBE Multifunction Oven bottom element
LFE Multifunction Oven fan element
MFM Multifunction Oven fan motor
MVL Multifunction Oven light bulb
MLS Multifunction Oven light switch
LOS Multifunction Oven switch block
LTI Multifunction Oven top inner element
LTO Multifunction Oven top outer element
NLI Neon indicator light
TCO Thermal cut out
Code Color
BK Black
BL Blue
BR Brown
GY Grey
OOrange
RRed
V Violet
WWhite
Y Yellow
