Lab 12 suono - Suono Tubes Position

Lab12 suono- 25W Class A Single Ended Power Amplifier
Page 5 of 9
Suono Tubes Positions
Insert the tubes carefully in each position. All tubes are marked with position number was placed during
calibration and burn in of suono.
All in box tubes are perfectly matched during calibration to achieve a perfect balanced operation.
V1 : KT150
V2 : KT150
V3 : 6n2p
V4 : 6n2p
