Front Panel
SUONO
Front
pane
l
In the front panel you will see three indication LEDs and two VU meters.
The three LEDs (C) indicate that the device is powered on.
To the left of the 3 LEDs, you will see a retro analog VU meter (A). You can accurately monitor the
output level of left channel on dB scale.
To the right of the 3 LEDs, you will see a retro analog VU meter (B). You can accurately monitor the
output level of right channel on dB scale.
