Item no. TDS-PLM10000Q_V13
L a b . g r u p p e n a b ▸ S w e d e n
i n t e r n a t i o n a L c o n t a c t ▸ i n f o @ L a b g r u p p e n . c o m | u S & c a n a d a c o n t a c t ▸ i n f o @ t c g - a m e r i c a S . c o m
w w w . l a b g r u p p e n . c o m
General
Number▸of▸input▸channels 2
Number▸of▸output▸channels 4
Peak▸total▸output▸ all▸channels▸driven 10800▸W
Max.▸Peak▸output▸voltage▸per▸channel 153▸V
Max.▸output▸current▸per▸channel 50▸A▸peak
▸ ▸
Max. Output Power 2 ohms 4 ohms 8 ohms 16 ohms
All▸channels▸driven 2350▸W 2300▸W 1300▸W 660▸W
Channels▸1▸and▸2,▸while▸channels▸3▸and▸4▸are▸driven▸at▸-3▸dB▸
2)
2350▸W 2400▸W 1300▸W 660▸W
All▸channels▸driven▸into▸optimal▸impedance▸interval▸ >▸2700▸W▸into▸2.4▸–▸3.2▸ohms
Audio Performance
THD▸+▸N▸20▸Hz▸-▸20▸kHz▸for▸1▸W <0.05%
THD▸+▸N▸at▸1▸kHz▸and▸1▸dB▸below▸clipping <0.04%
Dynamic▸range▸with▸digital▸inputs▸(for▸all▸supported▸sample▸rates) >116▸dB
Dynamic▸range▸with▸analog▸inputs >114▸dB
Frequency▸response▸(1▸W▸into▸8▸ohms,▸20▸Hz▸-▸20▸kHz) +▸/- 0.05▸dB
Input▸Common▸Mode▸Rejection▸(CMR)▸20▸Hz▸to▸1▸khz >▸78▸dB
Internal▸sample▸rate 96▸k
Internal▸data▸p ath 32▸bit▸oating▸point
Product▸propagation▸delay,▸best▸case▸(96▸kHz▸AES) 1.61▸ms
Product▸propagation▸delay,▸analog▸inp ut 1.68▸ms
Sample Rate Converters
THD▸+▸Noise 0.00003▸%,▸20▸Hz▸-▸20▸kHz,▸unweighted
Analog to Digital inputs
THD▸+▸Noise 0.00022▸%,▸typical▸at▸1▸kHz▸unweighted▸at▸+26▸dBu▸headroom▸setting
0.00033▸%,▸typical▸at▸20▸Hz▸and▸20▸kHz▸unweighted▸at▸+26▸dBu▸headroom▸setting
AES / EBU inputs
Supported▸resolutions ≤▸24▸bit
Supported▸sample▸rates 44.1,▸48,▸88.2,▸96,▸176.4,▸192▸kHz
Dante Audio Network
Supports▸redundant▸paths Yes
Flexible▸topology Yes
Network▸latency 0.8,▸1.3▸and▸4▸ms
Device presets
Local▸memory▸locations▸for▸the▸settings▸of▸the▸product 100
Limiters
Adjustable▸Inter-Sample▸Voltage▸Peak▸Limiter▸(ISVPL) 17.8▸-▸153▸V,▸step▸size▸0.1▸V
Current▸Peak▸Limiter▸<▸300▸ms 49▸A▸peak
Current▸Average▸Limiter▸(CAL)▸>▸300▸ms 25▸Arms
Limiter Max▸(rms▸and▸peak▸limiters)
▸▸▸▸▸▸▸▸▸▸▸▸▸▸▸▸▸▸–▸MaxRMS▸(rms▸voltage▸limiter) Yes
▸▸▸▸▸▸▸▸▸▸▸▸▸▸▸▸▸▸–▸MaxPeak▸(peak▸voltage▸lim iter) Yes
Gain
Amplier▸gain 22▸-▸44▸dB,▸step▸size▸0.1▸dB
Analog▸attenuator -Inf▸to▸0▸dB,▸step▸size▸0.25▸dB
Back panel interface
AES▸/▸EBU▸/▸I/O▸(input▸+▸link) 2▸x▸3-pin▸XLR
Analog,▸2-channel▸I/O▸(input▸+▸link) 4▸x▸3-pin▸XLR,▸electronically▸balanced
Output▸connectors Neutrik▸Spea kon▸(1▸x▸NLT8,▸2▸x▸NLT4)▸or▸4▸Binding▸Posts▸(pairs)▸(must▸be▸specied▸upon▸order)
Auto▸10/100,▸Auto▸Uplink 2▸x▸RJ45▸EtherCon
Control▸and▸monitoring▸interface Via▸Ethernet▸for▸Lake▸Controller▸software
Detach able▸mains▸cord Neutrik▸PowerCon▸32▸A
Cooling Two▸fans,▸front-to-rear▸airflow,▸temperature▸controlled▸speed
Front-panel user interface:
Display,▸daylight▸readable▸LCD 2.5▸inch
Fault/Warning/Limit/Clip▸indicators RGB▸LEDs
Mute▸and▸soft▸function▸buttons 8▸provided
Standby▸Power▸button On/Off
Mute▸Enable▸butt on Enables▸muting▸of▸outputs▸and▸inputs▸via▸soft-button▸keypad
Meter▸button Toggles▸through▸meter▸views
Menu▸button Provides▸a▸menu▸driven▸interface▸for▸full▸function▸front▸panel▸control
Rotary▸Encoder Yes
Exit▸button Provides▸a▸“back”▸function
Power
Operating▸voltage,▸230▸V▸/▸115▸V▸nominal▸
1)
140-265▸V▸/▸70-135▸V▸(45▸-▸66▸Hz)
Soft▸start▸/▸Inrush▸Current▸Draw Yes▸/▸max.▸5▸A
Mains▸Power▸Average▸Limiter▸(PAL) Yes
Dimensions (W/H/D) W:▸483▸mm▸(19”),▸H:▸88▸mm▸(2▸U),▸Overall▸D:▸470▸mm▸(18.5”)▸deep▸including▸handles▸and▸rear▸support.▸
Weight 13.5▸kg▸(30▸lbs.)
Finish Black▸painted▸steel▸chassis▸with▸black▸painted▸steel▸/▸aluminum▸front
Approvals CE,▸ANSI/UL▸60065▸(ETL),▸CSA▸C22.2▸NO.▸60065,▸FCC
Note 1):▸Sep arate▸230▸V▸or▸115▸V▸versions▸available.▸Not▸selectable▸on▸the▸product.
Note 2):▸Assymetrically▸loading▸the▸output▸channels▸(as▸shown,▸for▸example):▸If▸one▸channel▸has▸reduced▸output▸power▸requirements,▸the▸voltage▸drop▸from▸the▸power▸supply▸will▸be▸reduced,▸▸
▸▸▸▸▸▸▸▸▸▸▸▸▸▸▸▸▸▸▸resulting▸in▸a▸high er▸voltage▸and▸power▸output▸for▸the▸other▸channel.▸
▸ All specifications are subject to change without notice.
Interco oler,▸Class▸TD▸and▸Lake▸a re▸national▸and/or▸international▸ registered▸trademarks▸of▸ Lab.gruppen▸AB.▸PLM,▸Powered▸Loudspeaker▸Management,▸R.SMPS,▸LoadLibrary,▸ LoadSmart,▸▸
▸ SpeakerSafe▸and▸ISVPL▸are▸trademarks▸of▸Lab.gruppen▸AB.▸Dolby▸and▸the▸double-D▸symbol▸are▸registered▸trademarks▸of▸Dolby▸Laboratories.▸Contour,▸Mesa▸Quad▸EQ,▸Mesa▸Parametric▸EQ,▸Raised▸▸
▸ Cosine▸Equalization,▸Lim iterMax▸and▸I so-Float▸are▸trademarks▸of▸Dolby▸Laboratories.▸▸Audinate▸is▸a▸registered▸t rademark▸of▸Audina te▸Pty▸Ltd.▸Dante▸and▸Zen▸are▸trademarks▸of▸Audinate▸Pty▸Ltd.All▸▸
▸ other▸trademarks▸remain▸the▸property▸of▸their▸re spective▸owne rs.
▸ Copyright © 2009 Lab.gruppen AB.
All rights reserved.
