Edition 3 April 2012 Mars/Mars Pro Service Manual
Page 41/59
above should be 8, Replacement of window motor
Replacement of window motor
1: Under the 4 screws holding top plate and remove cover
2: Manually raise window and place block under window raising it about 50mm from worktop. This loosens belt
supporting window
3: Remove split pin at left hand end of window motor
4: Push back plate and pull out motor
