LaCie 5big Backup Server Configuration Guide

LaCie 5big Backup Server Setting Up Your LaCie 5big Backup Server
Configuration Guide page 14
2.2. Connecting the Ethernet Cable
The 5big Backup Server is accessible when attached to your network
(Fig. 07). The USB 2.0 and eSATA ports are for expansion only and
should not be used to connect the 5big Backup Server to a com-
puter.
1. Connect the Ethernet cable to the Ethernet port on the back of
the LaCie 5big Backup Server (1.4.2. Rear View).
2. Connect the other end of the Ethernet cable into an available
Ethernet port on your router.
3. Turn the server on if it is off. See 2.1. Turning On the 5big
Backup Server.
TECHNICAL INFORMATION: The 5big Backup Server must re-
ceive its IP address from a DHCP server.
DESIGNED BY NEIL POULTON
POWER
AUDIO OUTLAN 1 USB USB USB
eSATA
Fig. 07
