20-18071 Rev A
Articulation Overview
The Patient Simulator has a range of limb and joint articulation
providing immersive patient handling.
Joint Range of Mobility
Neck 3-axis movement of the head
Shoulder At least:
160° flexion of arm
30° extension of arm
70° abduction of arm
90° medial rotation
Elbow At least 90° flexion; 90° medial rotation
Thumbs Free mobility
Wrist Radial flexion and ulnar flexion
Lumbar 1-axis rotation
Hip Joints 3-axis rotation
Knees 1-axis rotation
Ankles 1-axis rotation
