20-18071 Rev A
Injection Sites Overview
1. Tension pneumothorax with needle decompression
can be performed at the bilateral mid clavicle line,
second intercostal space.
2. Intraosseous (IO) simulation with needle insertion
is possible through the left tibia and humeral in both
arms.
3. Intramuscular (IM) injections can be simulated in both
deltoid arm areas and upper hip.
4. Chest tube insertion can be simulated at left or right
mid-axillary line in the fourth and fifth intercostal
space.
5. Intravenous (IV) fluids can be simulated on both
Patient Simulator arms.
