Prepare Genitalia and Catheterization
SimMan 3G PLUS is fitted with neutral genitalia. It can be
replaced with the supplied male or female genitalia to simulate
catheterization.
1. Remove the Patient Simulator’s genitalia pad by gripping
the pad pulling forward and down.
2. Select new genitalia module.
3. Connect the new genitalia module’s urine tube and
the catheterization sensor cable from inside the Patient
Simulator pelvis to the urine bladder module.
4. Place the new genitalia module back into the Patient
Simulator’s pelvis.
Notes
• The Patient Simulator legs do not need to be removed before
the genitalia pad can be replaced.
• Common skin preparations such as chlorhexidine and
povidone iodine-based products may be used safely without
staining the genitalia.
• Always use a water-based lubricant liberally when inserting
a urine catheter.
Use the following catheter sizes
Female genitalia Foley 14Ch and Lofric 16Ch
Male genitalia Foley 16Ch and Lofric 16Ch
