laerdal SimMan 3G PLUS - Page 35

20-18071 Rev A
Prepare Trauma Arms (Accessory) 1/2
Removing Arm
1. Unzip torso skin.
2. Move stomach foam to one side.
3. Lift chest plate to expose arm bolt.
4. Unscrew the left arm bolt.
5. Disconnect all arm cables.
6. Remove arm.
Note
Do not unscrew the arm bolt fully.
