SimMan 3G PLUS
Intramuscular (IM) Injection
Intramuscular injections can be simulated in both the arms and
upper hip areas as shown.
Notes
• The Pelvis IM pad absorbs up to 15 ml of fluid.
• The Arm IM pads absorbs up to 10 ml of fluid.
To dry or replace the pad(s) refer to Maintaining IM Pads &
Sheets.
Recommended Device Sizes
IM needle 21 G (maximum)
