Automatic NIBP Monitoring
SimMan 3G PLUS enables bilateral, automatic NIBP monitoring
with a clinical monitor.
Note
Only use the Blood Pressure cuff supplied with SimMan 3G PLUS.
1. Locate correct connector (supplied) to connect BP cuff to
Patient Monitor.
2. Attach connector to BP cuff (use a Y-connector if the
patient monitor uses a dual tube).
3. Connect short tube with angled connector to BP port
and longer tube to the Patient Monitor.
The NIBP system delivers simulated blood pressures with
an accuracy of ≤ 5 mmHg or 3% of the reading whichever is
greater (at 15-25 °C, 15-85% RH).
NIBP system range
Diastolic blood pressure 40-130 mmHg
Systolic blood pressure 60-200 mmHg
Refer to LLEAP Help Files for complete blood pressure
measurements and operating information.
