20-18071 Rev A
Opening Torso
Some maintenance tasks can only be carried out by opening
the torso skin.
1. Unzip the skin at shoulders and torso.
2. Remove the genitalia pad.
3. Release the skin flap.
4. Move the skin to one side.
5. Move the stomach foam carefully to one side to avoid
pulling on connecting tubes and cables.
Note
Ensure that the tubes and cables are connected to the stomach
foam.
