20-18071 Rev A
Replacing the IV Port & Seal 1/2
Change the IV port or seal if they show signs of significant
wear and tear.
1. Unzip arm skin from shoulder to wrist.
2. Release IV port from chassis.
3. Rotate to release from tube.
4. Remove IV port completely from arm.
5. Remove used seal from inside IV port.
To Next Page
