laerdal SimMan 3G PLUS - Page 76

20-18071 Rev A
Replacing the IV Port & Seal 2/2
6. Discard used seal.
7. Insert a new seal into IV port.
8. Align and attach IV port to tube.
9. Rotate IV port to secure in place.
10. Click back into chassis.
11. Zip up arm skin.
