20-18071 Rev A
Replacing Tibial IO 1/2
1. Attach the Tibial IO drain bag to the Tibial tube.
2. Close off the pinch clamp.
3. Roll down leg skin to access the Tibial IO module.
4. Remove the IO tape
5. Lift out the Tibial IO unit from the leg.
6. Remove the tube from the Tibial IO module.
7. Remove the Tibial IO Pad from the Tibial IO chassis.
8. Discard used Tibial IO Pad.
9. Ensure the nipple is retracted on the new Tibial IO pad.
