20-18071 Rev A
Replacing Tibial IO 2/2
10. Secure the Tibial IO Pad into the chassis and press the
base of the pad until the nipple moves forward and locks
into place.
11. Connect the Tibial tube to the Tibial IO unit.
12. Insert the Tibial IO module into the leg.
13. Secure the module with tape.
14. Roll the leg skin over the Tibial module.
