INTRODUCTION
1.1 MACHINE FEATURES
Figure 1 (on page 2) depicts the TRIO with the main components
designated. Please take a little time to familiarize yourself with the
machine.
1.2 DESCRIPTION OF THE MACHINE
The TRIO works with three sanding discs that are suspended in a
freely rotating support. The working area is fully covered by the
machine housing. The motor and switchbox are positioned vertically
on the machine housing. One of the plugs leads to the power supply,
the other to the on/off switch which can be positioned either on the
switchbox or below the guide handle. The chassis consisting of the
bracket with wheels, tubular, adjustable handle is mounted to the
sanding unit with two crossnut fasteners and can be removed for
transport purposes.
A dust separator is fixed to the chassis and connected to the dust
suction system of the sanding unit by a flexible suction hose. Dust
is separated by a coarse filter system and collected in the dispos-
able dust bag. Inside the dust bag box the dust bag is fastened to
the separator with a MultiClip. The transparent dust bag box can
be opened using two fasteners. The air coming from the separator
passes through a fine particle filter behind the perforated cover
before being blown out into the environment. A sensor checks the
air-pressure in the separator and a red warning lamp lights up when
the suction capacity is too low.
To return to the correct suction capacity, the cleaning slide must
be used to clean the fine particle filter.
Introduction
1
You have chosen a high quality product
made by LÄGLER. We wish you every suc-
cess working with the TRIO. The machine
has been designed and constructed up to the
latest state-of-the-art standards. You can be
assured that each and every machine we
produce is submitted to a thorough opera-
tional test before leaving our premises.
Please read this operating manual in its
entirety prior to working with your TRIO for
the first time. It contains important infor-
mation which will help you to operate the
machine safely and without any problems.
Should a specific point of interest to you not
be addressed in this booklet, please don’t
hesitate to contact our service department
or your LÄGLER dealer. They have completed
a highly qualified training course and are
thus thoroughly acquainted with all aspects
of TRIO. They will be more than happy to give
you all the help and advice you need.
